When you choose an object, the object parameter window is displayed so that
the parameters could be modified.
You can use the cursor to choose (highlight) the object whose parameters you
wish to modify within the edit area. The appearance of a red setting-out frame
around the object is tantamount to choosing an object.
Touch the button to modify the parameters of a given object. The
window displayed as the result contains the parameters that are specific for a
given type of object and whose settings can be modified. If a new setting is of a
wrong type or out of the permissible range, the text field is highlighted in red.
Amend the setting accordingly.
Save the project with the button. The project is saved with the name that
was given to it when it was created or it had when it was opened. The button is
disabled when the project is already saved or when no modifications have been
made. If the project is not saved, the button is enabled; in addition, the
project name displayed at the top of the processor window is red (after saving it
changes the color to white).
A project can also be saved with another name by means of the button.
You can exit the processor with the button. In this way you abandon
editing and the project is not saved.
Repositioning an Object
Highlight an object in the edit area in order to change its position (a red setting-
out frame appears), and then touch the button – the setting-out frame
changes its color to green.
You can reposition an object in two ways:
by touching the screen anywhere in the edit area. The point of touch
defines the position of the top left-hand corner of an object (the entire
object framed in green is moved in relation to the given point).
By means of the , , , buttons. The object is
moved by 1 pixel with every touch.
The object is shifted provided that the project area is greater than the object to
be relocated.
Confirm the change in position with the button or abandon the change
with the button.
