Fit content to frame (not available to text objects where an EBS built-in
font is used and to barcode-type objects) – when the size of an object is to
be the same as the size of the frame.
If the Transparent parameter check box is ticked, the object is transparent and
you can see an object that is 'under' it. This property is useful when a number of
objects have been placed in the edit area and there is a risk that objects overlap
each other.
The Object rotation parameter allows you to rotate the entire object clockwise
(the setting of 90), counterclockwise (the setting of 270) or "upside down" (the
setting of 180).
The Position parameter shows the coordinates of the top left-hand corner of
the object frame. You can modify the coordinates and thereby change the
position of the object. Place the cursor in the Position field and modify the
coordinates in the window displayed. The first coordinate determines the
location in the horizontal direction (x coordinate), the second one determines
the location in the vertical direction (y coordinate). The repositioning operation
can also be performed in the edit area by holding the cursor on the object and
shifting it in any direction.
The Object size parameter defines the size of an object frame. Place the cursor
in the Object size field and modify the size components, (width and height) in
the window displayed. The resizing operation can also be performed in the edit
area, by holding the cursor on the bottom right-hand corner of the object and
dragging it in any direction (no frame can be resized if Scaling is set to Fit
frame to content).
The Position and Object size parameters are particularly useful when you
need to arrange or align two or more objects precisely.
The Object name parameter is designed for identification of an object in the
object list. The type of object and a number are used as the object name, as
standard (e.g. Text 1, Counter 2). You can give your own name to objects to
facilitate identification, but the same names must not be used, i.e. they must be
unique within one project. If you use a name that has already been used within
the project, an error is reported when you try to save the parameters of the
object named so.
If you tick the Show preview check box, an object preview is displayed in the
top left-hand corner of the screen.
Text Objects
Text Object – Normal Text
Touch the button and then in order to add a new, Normal Text-type
text object to a project.
