Patient Monitor User Manual Calculation and Titration Table
- 200 -
Dose Type
The data in the trend table will vary with the changes above. And the user can perform the
following:
Scroll up and down the screen by selecting and pressing the symbol and displayed
on the trend graph.
Record the data displayed in the current window by selecting Record.
25.2 Hemodynamic Calculation
25.2.1 Calculation Procedure
1. The hemodynamic calculation interface is displayed by selecting Menu > Common
Function > Calculation > Hemodynamics.
2.
Manually enter the values required on this interface. You can also directly obtain the values
of HR, C.O., PA MAP, CVP, and PAWP if they are available from the monitor by selecting
Get Info.
3.
Select Calculate to output parameter value.
25.2.2 Input Parameters
Items English Full Name/Description
PAWP Pulmonary artery wedge pressure
CVP Central venous pressure
C.O. Cardiac output
HR Heart rate
EDV End-diastolic volume
AP MAP Mean Artery Pressure
PA MAP Pulmonary artery mean pressure
Height /
Weight /
25.2.3 Output Parameters
Items English Full Name/Description
CI Cardiac index
BSA Body surface area
SV Stroke volume
SVI Stroke volume index
