Patient Monitor User Manual Product Specifications
- 278 -
Maximum Transmission Delay
(Diagnosis Mode)
500 ms
Sensitivity 1 V/1 mV ±10%
PACE Rejection/ Enhancement Not applicable.
Waveform Display Consistent with the calculation leads.
Compliant with Standard and
Directive
Complies with the requirements in terms of short circuit
protection and leakage current in EN60601-1.
Output Impedance < 500 Ω
Interface Type PS2 connector
NOTE:
While using analog output, set the calculation lead as following:
1) In 3-lead mode, set to Lead I, Lead II, or Lead III.
2) In 5-lead mode, set to Lead I, Lead II, Lead III or Lead V.
3) In 12-lead mode, set to Lead I, Lead II, Lead III or Lead V1~V6.
A.25.2 Defibrillator Synchronization
Output Impedance < 500 Ω
Maximum Time Delay 35 mS (R-wave peak to leading edge of pulse)
Waveform Rectangular wave
Amplitude High level: 3.5 V to 5.5 V, providing a maximum of 1 mA
output current;
Low level: < 0.5 V, receiving a maximum of 5 mA input
current
Minimum Required R-wave
Amplitude
0.3 mV
Pulse Width 100 mS±10%
Limited Current 15 mA rating
Rising and Falling Time < 1 mS
Interface Type PS2 connector
A.25.3 Nurse Call
Drive Mode Voltage output
Power Supply ≤ 12 VDC, 200 mA Max.
