Patient Monitor User Manual Monitoring ECG
- 97 -
8.6.7 ECG Waveform Settings
To change the speed, select ECG Waveform Setup > Sweep (mm/s), then select an appropriate
setting from the pop-up list. The bigger the value is, the wider the waveform is.
Select ECG Waveform Setup > Cascade: Turn on or off ECG cascade. Cascade means the ECG
waveforms displayed on the screen all occupy the area of two waveforms. This function is valid
only when Display is set to Normal.
8.7 12-Lead ECG Monitoring
In 12-lead display mode, 12 ECG waveforms and one rhythm lead waveform will be shown at the
waveform area on the screen. The rhythm lead is for ECG calculation before entering 12-lead
display mode. Also, in this mode, the filter mode is set to Diagnosis and can not be changed.
NOTE:
1 The 12-lead analysis results are for reference only and the analysis significance must
be determined by the physician.
2 If the ECG signal is too weak, the 12-lead analysis results might be affected.
3 Regarding to the standards' instructions for ECG measurement and analysis of the
monitor, please refer to Smart ECG Measurement and Interpretation Programs User
Manual_EDAN2.
8.7.1 Activating 12-Lead ECG Monitoring
Select Menu > Maintenance > User Maintain > Other Setups > 12 Leads Activate in order to
get the SN number which is supposed to be supplied to EDAN for a corresponding password.
Enter the password on the above-mentioned interface and restart the monitor, and the 12-lead
ECG monitoring function will be activated.
NOTE:
If the 12-lead ECG monitoring fails to be activated, users can reenter the password and
try to activate this function again.
8.7.2 Analysis Function
If your monitor is configured with the 12-lead ECG monitoring function, the monitor can perform
automatic analysis function. To perform 12-lead analysis analysis:
1. In the ECG Setup menu, set Lead Type to 12 Leads and set Display to 12 Leads.
2. Select the shortcut key on the screen directly.
3. The analysis results will be provided in the Diagnosis Review window after approximately
10 seconds.
The measurement function provides the automatic measurement of the common parameters, such
as heart rate, PR interval, QRS duration, QT/QTC interval, P/QRS/T axis, RV5/SV1 amplitude
