Patient Monitor User Manual Basic Operation
- 15 -
Chapter 3 Basic Operation
This user manual is based on the maximum configuration and therefore your monitor may not
have all of the functions and options described in the manual. Also, illustrations in this manual
serve as examples only and do not necessarily reflect the setup on your monitor. The content
displayed on your monitor depends on the way it has been tailored for your hospital.
You may frequently use the follow functions:
ECG monitoring (Refer to Chapter 8 Monitoring ECG for more information.)
SpO
2
monitoring (Refer to Chapter 10 Monitoring SpO
2
for more information.)
PR monitoring (Refer to Chapter 11 Monitoring PR for more information.)
NIBP monitoring (Refer to Chapter 12 Monitoring NIBP for more information.)
Alarm (Refer to Chapter 4 Alarms for more information.)
3.1 Overview
3.1.1 Main Unit
Front View
elite V5/ elite V6
