Patient Monitor User Manual Product Specifications
- 257 -
PI
Measuring Range 0-10, invalid PI value is 0.
Resolution 1
Nellcor Module
Measuring Range 1% to 100%
Resolution 1%
Data Update Period
1 s
Accuracy
DS-100A, OXI-A/N(Adult)
D-YS (Adult and Pediatric)
OXI-P/I (Pediatric)
± 3% (70% to 100% SpO
2
)
MAX-A, MAX-AL, MAX-N,
MAX-P, MAX-I, MAX-FAST
(Adult and Pediatric)
±2% (70%
100% SpO
2
)
MAX-A, MAX-AL, MAX-N,
MAX-P, MAX-I, MAX-FAST
(Adult and Pediatric)
±3% (60%
80% SpO
2
)
If sensor is used for neonate as recommended, the accuracy will be larger
than adult by ±1.
Sensor Wave length: approximately 660 nm and 900 nm
Emitted light energy: < 15 mW
NOTE:
The information about wavelength range can be especially useful to clinicians (for
instance, when photodynamic therapy is performed).
A.15 TEMP
Complies with ISO 80601-2-56: 2009.
Technique Thermal resistance
Position Skin, oral cavity, rectum
Measure Parameter T1, T2, TD (the absolute value of T2 minus T1)
Channel 2
Sensor Type YSI-10K and YSI-2.252K
Unit
°C, °F
Measuring Range
0
°C to 50 °C (32 ºF to 122 ºF)
