Patient Monitor User Manual Basic Operation
- 23 -
1 Speaker For alarm tones, pulse tones and so forth.
2 Equipotential
grounding terminal
If the monitor is used together with other
devices, connect this terminal to eliminate
potential ground differences between devices.
3 Power cable safety
latch
Used to prevent the power cable from loosing
or falling. Place the latch on the power cable
and press it down firmly to ensure that it
secures the power cable.
4 AC power input
5 SD card slot Used to mount an SD memory card.
6 VGA output It enables the VGA video output.
7 USB interfaces They support USB1.0/2.0 output.
8 Nurse call port/analog
output/defibrillator
synchronization
If users select it as nurse call, it connects the
monitor to the hospital’s nurse call system.
Alarms indications are alerted through the
nurse call system if configured to do so. If
users select it as analog output, the monitor
outputs the waveform through the port.
9 Network interface It connects the monitor to the central
monitoring system via standard network cable.
10 Extended video
interface
It connects a secondary display, which extends
the display capability of your monitor.
11 PAM connector It connects the Parameter Amplifier
Mainframe to the monitor.
12 RS232 interface Connect it to communicate with other devices.
13 Heat sink
14 Anti-thief lock
CAUTION
Connect only the EDAN Parameter Amplifier Mainframe to the PAM connector. Do not
connect any other device to this connector.
