Patient Monitor User Manual Alarm Information
- 77 -
TEMP alarm limits are listed as follows:
Adjustable Range
T1
0 °C (32 ºF)~50 °C (122 ºF)
T2
0 °C (32 ºF)~50 °C (122 ºF)
TD
High limit: 0.1 °C (32.18 ºF)~50 °C (122 ºF)
IBP alarm limits are listed as follows: unit (mmHg)
Adjustable Range
Art 0~300
RAP/ LAP/ CVP/ICP -10~40
PA -6~120
P1/P2 -50~300
CO
2
alarm limits are listed as follows:
Adjustable Range
EtCO
2
0 mmHg ~150 mmHg
FiCO
2
High limit: 0 mmHg ~50 mmHg
AwRR Sidestream: 2 rpm ~150 rpm
Mainstream: 0 rpm~150 rpm
C.O. alarm limits are listed as follows:
Adjustable Range
TB
23 °C (73.4 ºF)~43 °C (109.4 ºF)
AG alarm limits are listed as follows:
Masimo Module
Adjustable Range
FiCO
2
0.1%~25.0%
EtCO
2
0.0%~25.0%
FiO
2
18.0%~100.0%
EtO
2/
FiN
2
O/EtN
2
O 0.0%~100.0%
EtDes/FiDes 0%~18%
EtIso/FiIso/EtHal/FiHal/EtEnf/FiEnf 0%~5.0%
EtSev/ FiSev 0%~8%
AwRR 0 rpm~150 rpm
Apnea Time 20 s~40 s
