ESR series service routers.ESR-Series. User manual
In this configuration all calls will be directed to SIP proxy server. If it is necessary to specify another direction
for outgoing calls, you should perform the following:
Create a numbering plan, see section Dial plan configuration example.
Next, assign the created dial plan to the SIP profile:
esr(config)# sip profile 1
esr(config-sip-profile)# dialplan pattern firstDialplan
This completes the configuration of a dial plan for SIP profile.
Enable SIP profile:
esr-12v(config-sip-profile)# enable
This completes the baseline configuration of SIP profile:
esr(config-sip-profile)# exit
The next step is to configure subscriber ports:
esr(config)# interface voice-port 1
Specify a subscriber number:
esr(config-voice-port-fxs)# sip user phone 4101
Specify a displayed name:
esr(config-voice-port-fxs)# sip user display-name user-one
Used SIP profile:
esr(config-voice-port-fxs)# profile sip 1
Configure login and password for authentication
esr(config-voice-port-fxs)# authentication name login-4101
esr(config-voice-port-fxs)# authentication password superpassword
This completes the baseline configuration of a subscriber port:
esr(config-voice-port-fxs)# exit
