Table 3-13. Check point for the Maintenance Media Error according to each phenomenon
The error occurs even the
12cm CD/DVD is on the
CDR Tray.
1. Is the PW Sensor free from ink stain or paper dust?
1. Clean the surface of the PW
Sensor.
4.2.4.16 " Carriage Unit "
(p.154)
2. Is the PW Sensor connector cable properly connected to
the connector of the PW Sensor and CR Encoder board?
2. Connect the PW Sensor
connector cable correctly.
3. Is the PW Sensor connector Cable damaged?
3. Replace the Carriage Unit with a
new one.
4. Is the PW Sensor damaged?
4. Replace the Carriage Unit with a
new one.
1. Is the white marking of the CDR Tray free from ink stain
or paper dust?
1. Clean the marking of the CDR
Tray.
4.2.4.8 " CDR Tray Assy "
(p.140)
2. Is CDR Tray correctly installed?
2. Install CDR Tray correctly.
Table 3-14. Check point for the ADF Paper Jam Error according to each phenomenon
The error displays on the
LCD after initialization at
power-on.
1. Is the ADF Cover Assy closed?
1. Close the ADF Cover Assy.
4.2.6.2 " ADF Cover Assy/
ADF Cover L " (p.175)
The sheet is fed in the ADF
Unit, but reading does not
start, the error is displayed
instead.
1. Is the ADF Sensor Cable properly connected to CN51 on
the Main Board?
1. Connect the ADF sensor cable to
CN51 on the Main Board
correctly.
4.2.3.2 " Main Board /
Grounding Plate M/B "
(p.117)
2. Is the ADF Sensor Cable damaged?
2. Replace the ADF Frame Assy
with a new one.
4.2.6.8 " ADF Frame Unit "
(p.180)
1. Is the ADF Sensor Lever deformed?
1. Replace the ADF Frame Assy
with a new one.
4.2.6.8 " ADF Frame Unit "
(p.180)
1. Is the Spur Gear 6.4 correctly installed to ADF PF
Roller?
1. Install the Spur Gear 6.4
correctly.
4.2.6.10 " ADF PF Roller "
(p.183)
TROUBLESHOOTING Troubleshooting by Error Message 69
