Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
TROUBLESHOOTING
Troubleshooting by Error Message
https://www.manualsbooks.com
68
Confidential
Table 3-11. Check point for the Photo Tray Error according to each phenomenon
Occurrence
Timing
Symptoms
Failed Part /
Part Name
Check Point
Remedy
Reference
Any time
Photo Tray does not move
at all.
Cassette
1. Is the Cassette Unit correctly installed?
1. Install Cassette Unit correctly.
4.2.2.12 " Cassette Unit "
(p.114)
2. Is the Cassette Unit damaged?
2. Replace the Cassette Unit with a
new one.
Photo Tray
Sensor
1. Is the Photo Tray Sensor cable properly connected to
CN12 connector on the Main Board?
1. Connect the Photo Tray Sensor
cable correctly to CN12 on the
Main Board.
4.2.3.2 " Main Board /
Grounding Plate M/B "
(p.117)
2. Is Photo Tray Sensor cable damaged?
2. Replace the printer mechanism
with a new one
---
3. Is Photo Tray Sensor damaged?
3. Replace the printer mechanism
with a new one
Table 3-12. Check point for the CD size Error according to each phenomenon
Occurrence
Timing
Symptoms
Failed Part /
Part Name
Check Point
Remedy
Reference
Any time
The error occurs even the
12cm CD/DVD is on the
CDR Tray.
PW Sensor
1. Is the PW Sensor free from ink stain or paper dust?
1. Clean the surface of the PW
Sensor.
4.2.4.16 " Carriage Unit "
(p.154)
2. Is the PW Sensor connector cable properly connected to
the connector of the PW Sensor and CR Encoder board?
2. Connect the PW Sensor
connector cable correctly.
3. Is the PW Sensor connector cable damaged?
3. Replace the Carriage Unit with a
new one.
4. Is the PW Sensor damaged?
4. Replace the Carriage Unit with a
new one.
CDR Tray
1. Is the white marking of the CDR Tray free from ink stain
or paper dust?
1. Clean the marking of the CDR
Tray.
4.2.4.8 " CDR Tray Assy "
(p.140)
2. Is CDR Tray correctly installed?
2. Install the CDR Tray correctly.
