Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
TROUBLESHOOTING
Troubleshooting by Error Message
https://www.manualsbooks.com
67
Confidential
Table 3-8. Check point for the Paper Out Error according to each phenomenon
Occurrence
Timing
Symptoms
Failed Part /
Part Name
Check Point
Remedy
Reference
Any time
Paper is ejected just after
paper is fed.
PE Sensor
1. Is the connector cable of the PE Sensor properly
connected to CN9 connector on the Main Board?
1. Connect the connector cable of
the PE Sensor correctly to CN9
connector on the Main Board.
4.2.4.19 " Upper Paper
Guide L/R / PE Sensor "
(p.161)
2. Is the PE Sensor damaged?
2. Replace Front Paper Guide Assy
with a new one.
Upper Paper Guide
R
1. Is the lumiler protecting the PE Sensor contaminated?
1. Replace Upper Paper Guide Assy
with a new one.
Table 3-9. Check point for the Ink End Error / No Ink Cartridge Error / Incorrect Ink Cartridge Error according to each phenomenon
Occurrence
Timing
Symptoms
Failed Part /
Part Name
Check Point
Remedy
Reference
At power-on
The error occurs after the
carriage detected the home
position.
Ink Cartridge
1. Is the Memory chip on the Ink Cartridge disconnected or
damaged?
1. Replace the Ink Cartridge with a
new one.
---
CSIC FFC
1. Is the CSIC FFC properly connected to CN5 connector
on the Main Board and the connector on the CSIC Assy?
1. Connect the CSIC FFC correctly.
4.2.4.4 " CSIC Assy "
(p.132)
CSIC Assy
1. Is the CSIC terminal damaged?
1. Replace the CSIC Assy with a
new one.
4.2.4.4 " CSIC Assy "
(p.132)
2. Is the CR contact module damaged?
2. Replace the CSIC Assy with a
new one.
Table 3-10. Check point for the Scanner Open Error according to each phenomenon
Occurrence
Timing
Symptoms
Failed Part /
Part Name
Check Point
Remedy
Reference
Any time
The Printer Cover is closed,
but the cover open error is
displayed.
Scanner Cover
Open Sensor FFC
1. Is the Scanner Cover Open Sensor FFC properly
connected to CN10 connector on the Main Board?
1. Replace the Scanner Unit with a
new one.
• 4.2.5 " Disassembling
Scanner Unit " (p.167)
• 4.3.3 " Disassembling the
Scanner Unit (Artisan
700/PX700W/TX700W)
" (p.200)
2. Is the Scanner Cover Open Sensor FFC damaged?
2. Replace the Scanner Unit with a
new one.
Scanner Cover
Open Sensor
1. Is the Scanner Cover Open Sensor damaged?
1. Replace the Scanner Unit with a
new one.
Carriage Unit
1. Is the Sensor magnet of the Carriage Unit damaged?
1. Replace the Carriage Unit with a
new one.
4.2.5.3 " Scanner Carriage
Unit " (p.169)
Upper Housing
1. Is the Open Sensor magnet of the Upper Housing
damaged?
1. Replace the Upper Housing with
a new one.
4.2.2.5 " Upper Housing "
(p.107)
