DISASSEMBLY FLOWCHART
A1 B1
Start
Rear Cover (Back)
(→P. 471)
ASF Front Cover
(→P. 472)
Ink Eject Cover
(→P. 472)
Housing Right
(→P. 473)
Housing Left
(→P. 473)
ADF/SCN Unit
(→P. 474)
Housing Upper
(→P. 474)
Hinge Assy
(→P. 475)
Hinge Lower Cover
(→P. 476)
A8
C1
A2 B2
C2
A3 B3
C3
A4 B4
C4
A5 B5
C5
A6 B6
C6
A7 B7
C7
B8
C8
B9
D9
A9
B10
D10
A10
Extension Spring 11.11
(→P. 478)
CR Scale
(→P. 479)
PS Ground Plate
(→P. 479)
Rear ASF Upper Guide
Assy (→P. 480)
Main Board Assy
(→P. 480)
Head Screw Assy
(→P. 483)
Head Upper Cover
(→P. 483)
Printhead
(→P. 484)
Main Frame Assy
(→P. 487)
PE Assy
(→P. 488)
Cable Guide
(→P. 477)
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4 Housing (WF-
C5200 Series) (2) (p. 254) in the case of the WF-C5200 Series, and
remove the parts from the Rear Back Cover to the Housing Top.
 Implement the procedure indicated by when removing the Ink
Tube from the RIPS Unit and Printhead.
 The procedure indicated by is applicable only in the WF-C5700
Series/ET-8700.
Frame Plate
(→P. 487)
A11 B11
C11
A12
B12
C12
A13 B13
C13
A14 B14
C14
A15 B15
C15
A16
B16
C16
A17 B17
C17
A18 B18
C18
A19 B19
C19
A20 B20
C20
A21
B21
C21
A22
Rear ASF Assy
(→P. 476)
Paper Guide Upper
Assy (→P. 489)
B22
Paper Guide Upper Assy
Spring (→P. 489)
C22
Preparation for
Dissembling
Ink Discharge
(→P. 470)
Start
