Both power supplies are compatible with X460-G2 PoE switch models that have the same airflow
direction as the power supply.
The Summit 715 W AC PSU-FB power supply (Model 10951) is compatible with the X450-G2 PoE and
X465 PoE (-48P, X465-48W, X465-24MU, X465-24MU-24W, X465-24W, X465i-48W) switch models.
The Summit 715 W AC power supplies have a keyed power inlet (C16) that requires a notched (C15)
power cord.
The Summit 715 W AC power supplies have the status LEDs listed in Table 51.
Table 51: Summit 715 W AC Power Supply LED Status Indications
IN_OK
(Green)
OUT_OK
(Green or Red)
Description
O O No AC input power connection or low AC voltage.
On O AC input good, 54V output disabled.
On (Red) On AC input good, output (54V) fault.
On (Green) On AC input good, DC outputs in spec.
Summit 750 W AC Power Supply
The Summit 750 W AC power supply is used in the EPS-C2 external power system (see EPS-C2
Redundant Power System on page 122). Each installed Summit 750 W AC power supply can provide up
to 380 watts of PoE power budget.
The Summit 750 W AC power supply has the status LEDs listed in the following table.
Table 52: Summit 750 W AC Power Supply LED Status Indications
Label and Color State Meaning
AC OK
Green
O No AC input
On AC input is good.
DC OK
Green
O Both DC outputs (55 V and 12 V) are bad or not enabled.
Blinking One output is enabled and good; the second output is bad or not
enabled.
On Both the 55 V and 12 V outputs are enabled and good.
ALM
Red
O No fault condition exists.
Blinking Power supply alert: power supply is likely to fail because of a developing
fault, such as abnormal thermal conditions or poor fan performance.
or
One output (55 V or 12 V) is bad.
On Both outputs (55 V and 12 V) are bad.
Power supply is receiving 3.3 VSB from the system. (AC OK and DC OK
are o.)
Thermal shutdown, fan failure, or any fault condition when both 55 V and
12 V are turned OFF.
