Summit 1100 W DC Power Supplies (10962, 10963)
Table 322: Physical Specifications
Dimensions Height: 1.57 inches (4.0 cm)
Width: 3.25 inches (8.3 cm)
Length: 10.22 inches (26.0 cm)
Weight 2.55 lb (1.12 kg)
Table 323: Power Specifications
Nominal input -48 to -60 VDC, 24 A
DC Voltage input range -35 to -75 V
Inrush Current 21 A peak
Maximum wire size 14 AWG (1.5 mm2 copper stranded).
DC Output 12 V, 45 A/3.3V, 3A
DC Output Power (W) 1100 W
Table 324: Environmental Specifications
Operating temperature -10°C to 50°C (normal operation)
Storage temperature -40°C to 70°C
Operating humidity 93% relative humidity, non-condensing at 30C
Operational shock 30 m/s
2
(3 G)
ExtremeSwitching 2000 W Power Supply Technical Specifications
The ExtremeSwitching 2000 W AC power supply with front-to-back airflow (part no. XN-
ACPWR-200W-F) is available for use in X465-24W/48P/48W/24MU/24MU-24W and X465i-48W PoE
switch models:
Table 325: Physical Specifications
Dimensions (with handle) Height: 1.57 inches (4 cm)
Width: 3.25 inches (8.25 cm)
Length: 11.51 inches (29.25 cm)
Dimensions (without handle) Height: 1.57 inches (4 cm)
Width: 3.25 inches (8.25 cm)
Length: 10.25 inches (26.05 cm)
Weight 2.95 lb (1.34 kg)
Table 326: Power Specifications
Voltage input range
100-200 50 to 60Hz
Nominal input ratings 12.5 A max at 115VAC and 6A max at 230VAC at Full 770 W load
Summit 1100 W DC Power Supplies (10962, 10963) Technical Specifications
464 ExtremeSwitching Hardware Installation Guide
