Extreme Networks ExtremeSwitching X435 Series User Manual

Selecting Stacking Cables
Depending on the switch model and the number and type of stacking ports, the bidirectional stacking
link provides 40 Gbps, 80 Gbps, or 160 Gbps full-duplex bandwidth.
Stacking connections using the native stacking ports require stacking cables that are specific to the
type of stacking port. These cables are available from Extreme Networks in lengths from 0.5 meter to
100 meters.
Table 95 lists the cable types that have been verified by Extreme Networks for use as stack connection
hardware, along with the switches or modules with which each type is compatible.
Caution
Use of non-recommended cables or optics could cause stack instability.
Note
You can use certain other fiber cables and optical transceivers for stacking on X590, X690,
and X870 switches. Additional configuration is required. For details, see Alternative
Configuration for Optics on X590, X690, X695, and X870 Switches on page 211.
Table 95: Available Stacking Cables for Extreme Networks Switches
Part
Number
Cable Type, Length Compatible Ports and Devices
16105 SummitStack, 5 meter 20-Gbps stacking ports on VIM-2ss on X460-G2
switches
16106 SummitStack, 0.5 meter
16107 SummitStack, 1.5 meter
16108 SummitStack, 3 meter
10304 10GBASE-CR SFP+ pre-terminated
twin-ax copper cable, 1 meter
10G stacking ports on X440-G2, X450-G2 10G, and
X620 switches
10305 10GBASE-CR SFP+ pre-terminated
twin-ax copper cable, 3 meters
10306 10GBASE-CR SFP+ pre-terminated
twin-ax copper cable, 5 meters
10307 10GBASE-CR SFP+ pre-terminated
twin-ax copper cable, 10 meters
10G stacking ports on X440-G2 (48-port switches
only) and X450-G2 10G switches
10311 QSFP+ direct-attach passive
copper cable, 0.5 meter
21-Gbps stacking ports on X450-G2 switches, QSFP+
ports on X670-G2-48x-4q switches
40-Gbps stacking ports on X465, VIM5-4x, and
VIM5-4XE
10312 QSFP+ direct-attach passive
copper cable, 1 meter
21-Gbps stacking ports on X450-G2 switches, QSFP+
ports on X670-G2-48x-4q switches
40-Gbps stacking ports on X465, VIM5-4x, and
VIM5-4XE
10313 QSFP+ direct-attach passive
copper cable, 3 meters
21-Gbps stacking ports on X450-G2 switches, QSFP+
ports on X670-G2-48x-4q switches
40-Gbps stacking ports on X465, VIM5-4x, and
VIM5-4XE
Building Stacks Selecting Stacking Cables
ExtremeSwitching Hardware Installation Guide 209
