• VIM5-4X versatile interface module that provides four 10-GbE (SFP+) ports.
• VIM5-4XE versatile interface module that provides four 10-GbE (SFP+) ports, LRM/MACsec capable.
• VIM5-4Y versatile interface modulethat provides four 25-GbE (SFP28) ports.
• VIM5-4YE versatile interface module that provides four 25-GbE (SFP28) MACsec capable ports.
For 48-port models, the VIM5 ports are 49-56. For 24-port models, the VIM5 ports are 25-32.
VIM5s are ordered separately. Each VIM5's label can be found on the bottom side of the device, as seen
in the following figure:
Figure 134: VIM5 Label
1 = VIM5 label
VIM5-2Q Versatile Interface Module
The VIM5-2Q versatile interface module provides two 40-GbE (QSFP) ports.
Note
For the VIM5-2Q versatile interface module, only the first 40-GbE (QSFP) port is supported
on the X465-48T/48P/48W, X465i-48W, and X465-24W/24S models. Both 40-GbE (QSFP)
ports are supported on the X465-24MU-24W and X465-24MU/24XE models.
For information about the supported optical modules, refer to the most recent version of the Extreme
Hardware/Software Compatibility and Recommendation Matrices.
VIM5-2Q Versatile Interface Module
Expansion Modules
152 ExtremeSwitching Hardware Installation Guide
