Power Options
Table 228: X690 Power Options
X690-48t-2q-4c (part # 17360)
X690-48x-2q-4c (part # 17350)
770 W AC power supply:
Part # 10960 770 W AC PS FB (front-back)
Part # 10961 770 W AC PS FB (back-front)
AC Input: 100-240 VAC, 50/60 Hz
PSU Input Socket: IEC 320 C14
Power cord input plug: IEC 320 C13
1100 W DC power supply:
Part # 10962 1100 W DC PS FB (front-back)
Part # 10963 1100 W DC PS FB (back-front)
DC Input: -48 VDC
Table 229: Power Specifications
Switch Model
X690-48t-2q-4c AC Input: 100-127 VAC, 4.0 A max. per PSU, 50/60 Hz
AC Input: 200-240 VAC, 2.0 A max. per PSU, 50/60 Hz
DC Input: -48 to 60 VDC, 8.0 A max. per PSU
X690-48x-2q-4c AC Input: 100-127 VAC, 3.0 A max. per PSU, 50/60 Hz
AC Input: 200-240 VAC, 1.5 A max. per PSU, 50/60 Hz
DC Input: -48 to 60 VDC, 6.0 A max. per PSU
Table 230: X690 Power Consumption
Switch Model Minimum Heat
Dissipation
(BTU/hr)
Minimum Power
Consumption
(W)
Maximum Heat
Dissipation
(BTU/hr)
Maximum
Power
Consumption
(W)
X690-48x-2q-4c AC 282 BTU/hr 83 W 1124 BTU/hr 329 W
X690-48x-2q-4c DC 311 BTU/hr 91 W 1178 BTU/hr 345 W
X690-48t-2q-4c AC 425 BTU/hr 125 W 1271 BTU/hr 373 W
X690-48t-2q-4c DC 421 BTU/hr 123 W 1315 BTU/hr 385 W
1 PSU 2 PSU
CPU, Memory
CPU/Memory
1 GHz 64-bit CPU
2 GB DDR3 ECC SDRA memory
4 GB eMMC Flash Memory
12 MB buer, per chip
Technical Specifications Power Options
ExtremeSwitching Hardware Installation Guide 431
