2 = Pin 9 4 = Pin 18
Table 349: STK-RPS-1005PS Connector Pin Functions
Pin Function Pin Function
1 12 V power 10 Power good of RPS
2 12 V power 11 Power supply present
3 12 V power 12 12 V current sharing
4 Ground 13 Ground
5 Ground 14 Spare pin
6 Spare pin 15 -55 V current sharing
7 -55 V power 16 -55 V power
8 -55 V power 17 -55 V power return
9 -55 V power return 18 -55 V power return
VX-RPS-1000 Redundant Power Supply Technical Specifications
The following tables list the specifications for the model VX-RPS-1000 Redundant Power Supply.
Table 350: VX-RPS-1000 Unpackaged Dimensions
Height: 1.64 inches (4.17 cm)
Width: 5.27 inches (13.4 cm)
Length: 15.21 inches (38.6 cm)
Weight: 11.51 lb (5.22 kg)
Table 351: VX-RPS-1000 Packaged Dimensions
Height: 5.04 inches (12.8 cm)
Width: 12.57 inches (31.9 cm)
Length: 21.91 inches (55.6 cm)
Weight: 13.00 lb (5.89 kg)
Table 352: VX-RPS-1000 Power Specifications
AC input frequency range 50/60 Hz
AC input voltage range 100-120 VAC or 200-240 VAC
AC input current 12 A maximum at 120 VAC, 60 Hz
6.0 A maximum at 240 VAC, 50 Hz
Technical Specifications
VX-RPS-1000 Redundant Power Supply Technical
Specifications
ExtremeSwitching Hardware Installation Guide 473
