Extreme Networks ExtremeSwitching X435 Series User Manual

Figure 4: X435-8P-4S Rear Panel
ExtremeSwitching X435-8P-2T-W Switch Features
The front panel of the X435-8P-2T-W switch includes:
• Eight 10/100/1000BASE-T PoE+ ports that provide 8 Gbps of high-density copper connectivity. In
addition, all of these ports (ports 1-8) support the POE protocol IEEE802.3af and PoE+ protocol
IEEE802.3at standard.
All X435 PoE models can provide up to 15.4W by using PoE protocol, and provide up to 30W by
using PoE+ protocol on a single port.
• Two unpopulated 10/100/1000BASE-T 802.3bt ports that support copper connectivity
• One RJ-45 console port
• One USB A port
• LEDs to indicate port status and switch operating conditions
For a description of the LEDs and their operation, see ExtremeSwitching X435 Series Switch LEDs on
page 28
Figure 5: X435-8P-2T-W Front Panel
1 = System LEDs 3 = RJ-45 console port 5 = 10/100/1000BASE-T 802.3bt ports
2 = USB A port 4 = 10/100/1000BASE-T PoE+ ports
ExtremeSwitching Switches ExtremeSwitching X435-8P-2T-W Switch Features
ExtremeSwitching Hardware Installation Guide 25
