Installing Expansion Modules
Installing a V300 Virtual Port Extender on page 294
Installing a V400 Virtual Port Extender on page 316
Installing an LRM/MACsec Adapter on page 316
Installing a Half-Duplex to Full-Duplex Converter on page 320
Installing a Versatile Interface Module or Clock Module in an X460-G2 Series
Switch on page 322
Installing a Versatile Interface Module in an X465 Series Switch on page 324
Install an SSD Module on page 325
This chapter describes how to install expansion modules:
• The V300 Virtual Port Extender
• The V400 Virtual Port Extender
• The LRM/MACsec Adapter
•
The Half-Duplex to Full-Duplex Converter
• Versatile interface modules (VIM/VIM5s)
• Solid-state Drive (SSD) modules
Note
Read the information in this chapter thoroughly before trying install or remove an expansion
module.
To install port option cards, VIMs, and stacking modules that work with other Extreme Networks
switches, refer to ExtremeSwitching and Summit Switches: Hardware Installation Guide for Switches
Using ExtremeXOS 16 or Earlier.
Installing a V300 Virtual Port Extender
The following installation instructions are applicable to the V300-8P-2T-W (PoE) model. The
V300-8P-2X, V300-8T-2X, V300HT-8P-2X, and V300HT-8T-2X models will be referred to as non-PoE
models from this point on.
You need the following tools and materials to install a V300 Virtual Port Extender:
• ESD-preventive wrist strap
• M3.5 or M4 #2 Phillips screwdriver (magnetic screwdriver recommended)
294
ExtremeSwitching Hardware Installation Guide
