Figure 124: V300 Virtual Port Extender Rear Panel
V300-8P-2T-W Model
The Virtual Port Extender V300-8P-2T-W model oers the following features:
• 8 10/100/1000BASE-T half duplex PoE+ ports
• 2 1000/BASE-T 802.3bt Type 4 ports
• PoE power
• Fanless
The V300-8P-2T-W model requires that ExtremeXOS (EXOS) version 30.2.2 (or later) be installed on
the switch to which it is attached. For more information about
configuring EXOS for use with this
equipment, see the ExtremeXOS 30.7 User Guide.
Figure 125: V300-8P-2T-W Front Panel
1 = 10/100/1000BASE-T PoE ports
2 = 1000/BASE-T 802.3bt PD up-link
Figure 126: V300-8P-2T-W Rear Panel
V300HT-8P-2X Model
The Virtual Port Extender V300HT-8P-2X model is a high-temperature model that oers the following
features:
• Eight 10/100/1000BASE-T half/full duplex PoE+ ports
• Two 10Gb SFP+ ports
Expansion Modules
V300-8P-2T-W Model
ExtremeSwitching Hardware Installation Guide 143
