Table 233: Telecom Standards (continued)
MEF9 and MEF14 certified for EPL, EVPL, and ELAN
Table 234: IEEE 802.3 Media Access Standards
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
IEEE 802.3ae 10GBASE-X
IEEE 802.3ba 40GBASE-X
Table 235: Environmental Data
Environmental standards EN/ETSI 300 019-2-1 v2.1.2 (2000 - 2009) - Class 1.2 Storage
EN/ETSI 300 019-2-2 v2.1.2 (1999 - 09) - Class 2.3 Transportation
EN/ETSI 300 019-2-3 v2.1.2 (2003 - 04) - Class 3.1e Operational
EN/ETSI 300 753 (1997-10) - Acoustic Noise
ASTM D3580 Random Vibration Unpackaged 1.5G
Operating conditions Temperature range: 0°C to 45°C (32°F to 113°F)
Humidity: 5% to 95% relative humidity, non-condensing
Altitude: 0 to 3,000 meters (9,850 feet)
Operational shock (half sine): 30 m/s
2
(3 G), 11 ms, 60 shocks
Operational random vibration: 3 to 500 Hz at 1.5 G rms
Storage & transportation
conditions (packaged)
Transportation temperature: -40°C to 70°C (-40°F to 158°F)
Storage and transportation humidity: 10% to 95% relative humidity,
non-condensing
Packaged shock (half sine): 180 m/s
2
(18 G), 6 ms, 600 shocks
Packaged sine vibration: 5 to 62 Hz at velocity 5 mm/s,
62 to 500 Hz at 0.2 G
Packaged random vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct.
from 20 to 200 Hz
14 drops minimum on sides and corners at 42 inches (<15 kg box)
ExtremeSwitching X695 Series Switch Technical Specifications
The ExtremeSwitching X695-48Y-8C switch includes six unpopulated fan slots and two unpopulated
power supply slots.
Table 236: X695 Unpackaged Dimensions
X695-48Y-8C switch Height: 4.34 cm (1.71 in)
Width: 43.96 cm (17.31 in)
Length: 53.95 cm (21.24 in)
Fan unit, front-to-back or back-to-front Height: 4.0 cm (1.57 in)
Width: 4.0 cm (1.57 in)
Length: 13.4 cm (5.28 in)
Technical Specifications
ExtremeSwitching X695 Series Switch Technical
Specifications
ExtremeSwitching Hardware Installation Guide 433
