Installing External Power Supplies
Safety Considerations for Installing Power Supplies on page 263
Pre-installation Requirements on page 264
Installing an EPS-C2 Power Supply on page 264
Installing an RPS-150XT Redundant Power Supply on page 273
Installing an RPS-500p Redundant Power Supply on page 277
Installing an STK-RPS-150PS Redundant Power Supply on page 280
Installing an STK-RPS-1005PS Redundant Power Supply on page 286
Installing a VX-RPS-1000 Redundant Power Supply on page 290
Read the information in the following sections thoroughly before you attempt to install or remove an
external power supply.
For information about installing external power supplies that work with other Extreme Networks
switches, refer to ExtremeSwitching and Summit Switches: Hardware Installation Guide for Switches
Using ExtremeXOS 16 or Earlier.
Safety Considerations for Installing Power Supplies
Only trained service personnel should perform service to Extreme Networks switches and their
components.
Trained service personnel have read all related installation manuals, have the technical training and
experience necessary to be aware of the hazards to which they are exposed in performing a task, and
are aware of measures to minimize the danger to themselves or other persons.
Caution
Extreme Redundant Power Supplies (RPS) do not support the ability for the RPS to be
connected to an operational switch. Connecting an RPS to an operational switch can have an
adverse eîš‚ect on the switch. It is best practice that both the switch and the RPS be powered
down prior to cabling them together. Once the cabling is completed, turn on the RPS, then
turn on the switch.
Warning
Extreme Networks AC power supplies do not have switches for turning the unit on and oîš‚. To
disconnect the power to an Extreme Networks AC power supply, remove the wall plug from
the electrical outlet. Make sure that this connection is easily accessible.
ExtremeSwitching Hardware Installation Guide 263
