Table 301: DC Power Specifications (Models 10926 and 10928) (continued)
DC Output
12 V , 45 A/3.3 V , 3.0 A
DC Output Power (W) 550 W
Table 302: Environmental Specifications
Operating temperature 0°C to 45°C (normal operation)
Storage temperature -40°C to 70°C
Operating humidity 20% to 90% relative humidity, non-condensing
Operating altitude Up to 10,000 feet
Operational shock
Frequency Range 5 to 350 Hz, 200 to 2000 Hz PSD: 0.0001g2/Hz
350 to 500 Hz -6dB/Octave, 500 Hz 0.000052 Hz
Acceleration 0.21.0 gRMS (Typical Level)
Duration: 20 min per axis
Summit 715 W Power Supplies Technical Specifications
The following Summit 715 W power supplies are available for use in Summit X460-G2 series switches.
• Summit 715 W AC power supply: front-to-back airflow (part no. 10951)
• Summit 715 W AC power supply: back-to-front
airflow (part no. 10952)
Model 10951 (front-to-back airflow) is also compatible with the Summit X450-G2 and ExtremeSwitching
X465-24W/48P/48W/24MU/24MU-24W and X465i-48W PoE switch models.
Table 303: Physical Specifications
Dimensions Height: 1.57 inches (4.0 cm)
Width: 3.25 inches (8.3 cm)
Length: 10.22 inches (26.0 cm)
Weight 2.55 lb (1.12 kg)
Table 304: Power Specifications
Voltage input range
100-127/200-240 47 to 63Hz
Nominal input ratings 12.5 A max at 115VAC and 6A max at 230VAC at Full 715 W load
Maximum inrush current 45A at Max 264 VAC at 25C with cold start
Output 54 V, 13.2 A max, 715 W
Power supply input socket and cord IEC/EN 60320-1/C16 AC input receptacles
Technical Specifications Summit 715 W Power Supplies Technical Specifications
ExtremeSwitching Hardware Installation Guide 457
