Table 190: Power and Heat Dissipation
Minimum
16
Heat
Dissipation (1
PSU)
Minimum
16
Power
Consumption
Maximum
16
Heat
Dissipation (2
PSUs)
Maximum
16
Power
Consumption
X590-24t-1q-2c-AC 310.97 BTU/hr 91.14 W 792.27 BTU/hr 232.20 W
X590-24t-1q-2c-DC 332.63 BTU/hr 97.49 W 833.62 BTU/hr 244.32 W
X590-24x-1q-2c-AC 278.42 BTU/hr 81.60 W 743.82 BTU/hr 218.00 W
X590-24x-1q-2c-DC 286.61 BTU/hr 84.00 W 786.12 BTU/hr 230.40 W
CPU, Memory
CPU/Memory
1GHz 64-bit CPU
2GB DDR3 ECC SDRA memory
4GB eMMC Flash Memory
12 MB buer, per chip
16
Minimum is defined as idle, with no ports linked. Maximum is defined as fans high, all ports 100% trac.
CPU, Memory Technical Specifications
418 ExtremeSwitching Hardware Installation Guide
