Table 330: Power Specifications (continued)
Output voltage 19 VDC
Maximum output power 90 W
Table 331: Environmental Specifications
Operating temperature 0°C to 40°C (32°F to 104°F)
Storage temperature -20°C to 85°C (-4°F to 185°F)
Operating relative humidity 10% to 90%
Storage relative humidity 5% to 95%
RPS-150XT Redundant Power Supply Technical Specifications
The following tables list the specifications for the 150 W RPS-150XT Redundant Power Supply unit
(model 10932).
Table 332: Physical Specifications
Dimensions 4.1 H x 15.4 W x 30.0 D (cm) 1.61 H x 6.1 W x 11.8 D (in)
Weight (unit only) 1.5 kg (3.3 lb)
Weight (unit and packaging) approximately 3 kg (6.6 lb)
Table 333: Power Specifications
AC input frequency 50/60 Hz (range 47-63 Hz)
AC input voltage
100-240 V (range 90-264 V )
AC input current 2 A maximum (range 2 A at 100 V, 1 A at 200 V)
DC output
+12.0 V , 13 A maximum
Maximum output power 156 W
Table 334: Environmental Specifications
Operating temperature 0°C to 60°C (32°F to 140°F)
Storage temperature -45°C to 85°C (-49°F to 185°F)
Operating relative humidity 10% to 90% operating/95% non-condensing
RPS-150XT Redundant Power Supply Technical
Specifications Technical Specifications
466 ExtremeSwitching Hardware Installation Guide
