Extreme Standby Router Protocol
ExtremeWare XOS 11.3 Concepts Guide
480
NOTE
If your network has switches running ExtremeWare and ExtremeWare XOS participating in ESRP, Extreme Networks
recommends that the ExtremeWare XOS switches operate in ESRP standard mode. To change the mode of operation,
use the configure esrp mode [extended | standard] command.
The commands used to configure the BlackDiamond 10K switches are as follows:
create vlan sales
configure vlan sales add ports 1:1-1:4
configure vlan sales ipaddress 10.1.2.3/24
enable ipforwarding
create esrp esrp1
configure esrp esrp1 domain-id 4096
configure esrp esrp1 add master sales
enable esrp esrp1
configure ospf add vlan sales area 0.0.0.0 passive
configure ospf routerid 5.5.5.5
enable ospf
