RIP
ExtremeWare XOS 11.3 Concepts Guide
534
Figure 66: Route redistribution
Configuring Route Redistribution
Exporting routes from one protocol to another and from that protocol to the first one are discreet
configuration functions. For example, to run OSPF and RIP simultaneously, you must first configure
both protocols and then verify the independent operation of each. Then you can configure the routes to
export from OSPF to RIP and the routes to export from RIP to OSPF. Likewise, for any other
combinations of protocols, you must separately configure each to export routes to the other.
Redistributing Routes into RIP
Enable or disable the exporting of static, direct, BGP-learned, and OSPF-learned routes into the RIP
domain using the following commands:
enable rip export [bgp | direct | e-bgp | i-bgp | ospf | ospf-extern1 | ospf-extern2 |
ospf-inter | ospf-intra | static] [cost <number> {tag <number>} | policy <policy-
name>]
disable rip export [bgp | direct | e-bgp | i-bgp | ospf | ospf-extern1 | ospf-extern2
| ospf-inter | ospf-intra | static]
EX_046
OSPF AS
Backbone Area
0.0.0.0
Area
121.2.3.4
ABR
ASBR ASBR
RIP AS
