Switch Port Mirroring
ExtremeWare XOS 11.3 Concepts Guide
129
The following is an example of the output you see when you display the LACP information for port 5
on the Summit X450 switch:
Member Rx Sel Mux Actor Partner
Port State Logic State Flags Port
--------------------------------------------------------------------------------
5 Current Selected Collect-Dist A-GSCD-- 1005
================================================================================
Actor Flags: A-Activity, T-Timeout, G-Aggregation, S-Synchronization
C-Collecting, D-Distributing, F-Defaulted, E-Expired
The following is an example of the output you see when you add the detail parameter for port 5 on
the Summit X450 switch:
Member Rx Sel Mux Actor Partner
Port State Logic State Flags Port
--------------------------------------------------------------------------------
5 Current Selected Collect-Dist A-GSCD-- 1005
Up : Yes
Enabled : Yes
Link State : Up
Ready_N : Yes
Wait pending : No
Ack pending : No
LAG Id:
S.pri:0 , S.id:00:04:96:1f:a5:2e, K:0x03ed, P.pri:0 , P.num:1005
T.pri:0 , T.id:00:04:96:1f:a5:76, L:0x03ed, Q.pri:0 , Q.num:1005
Stats:
Rx - Accepted : 13980
Rx - Dropped due to error in verifying PDU : 0
Rx - Dropped due to LACP not being up on this port : 0
Rx - Dropped due to matching own MAC : 0
Tx - Sent successfully : 13979
Tx - Transmit error : 0
================================================================================
Actor Flags: A-Activity, T-Timeout, G-Aggregation, S-Synchronization
C-Collecting, D-Distributing, F-Defaulted, E-Expired
Refer to “Displaying Port Configuration Information” for information on displaying summary load-
sharing information.
To clear the counters, issue the following command:
clear lacp counters
Switch Port Mirroring
NOTE
Beginning with ExtremeWare XOS software version 11.2, you can accomplish port mirroring using ACLs or
CLEARFlow. See Chapter 13 for more information on ACLs and Chapter 18 for more information on CLEAR-Flow.
