RIP Configuration Example
ExtremeWare XOS 11.3 Concepts Guide
535
These commands enable or disable the exporting of static, direct, and OSPF-learned routes into the RIP
domain. You can choose which types of OSPF routes are injected, or you can simply choose
ospf, which
will inject all learned OSPF routes regardless of type. The default setting is disabled.
RIP Configuration Example
Figure 67 illustrates a BlackDiamond switch that has three VLANs defined as follows:
● Finance
■ Protocol-sensitive VLAN using the IP protocol.
■ All ports on slots 1 and 3 have been assigned.
■ IP address 192.207.35.1.
● Personnel
■ Protocol-sensitive VLAN using the IP protocol.
■ All ports on slots 2 and 4 have been assigned.
■ IP address 192.207.36.1.
● MyCompany
■ Port-based VLAN.
■ All ports on slots 1 through 4 have been assigned.
This example does use protocol-sensitive VLANs that only admit IP packets. This is not a common
requirement for most networks. In most cases, VLANs will admit different types of packets to be
forwarded to the hosts and servers on the network.
