Inserting Powered Devices in the PoE Module—BlackDiamond 8800 Family of Switches Only
ExtremeWare XOS 11.3 Concepts Guide
633
Inserting Powered Devices in the PoE Module—
BlackDiamond 8800 Family of Switches Only
To reduce the chances of ports fluctuating between powered and non-powered states, newly inserted
powered devices (PDs) are not powered when the actual delivered power for the module is within
approximately 19 W of the configured inline power budget for that slot. However, actual aggregate
power can be delivered up to the configured inline power budget for the slot (for example, when
delivered power from ports increases or when the configured inline power budget for the slot is
reduced).
Untagged Frames on the 10 Gbps Module—
BlackDiamond 10K Switch Only
On the BlackDiamond 10K switch, the 10 Gbps module must have the serial number 804405-00-09 or
higher to support untagged frames. To display the serial number of the module, issue the
show slot
<slot_number>
command. (All the modules for the BlackDiamond 8800 family of switches support
tagged and untagged frames.)
Running MSM Diagnostics from the Bootloader—
BlackDiamond 10K Switch Only
If you experience problems with your MSM module, or you are unable to use the run diagnostics
command, you can enter the Bootloader and issue a series of commands to run diagnostics on the MSM.
To access the Bootloader:
1 Attach a serial cable to the console port of the MSM.
2 Attach the other end of the serial cable to a properly configured terminal or terminal emulator.
