Fargo DTC400e - Running the Self Test

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
4-54
Running the Self Test
Perform a self-test after (a) an initial setup of the Printer, (b) a calibration procedure has
been conducted or (c) a part has been replaced to check for proper Printer operation.
Step Procedure
1 Verify that a full-color or Premium Resin Ribbon Cartridge is installed and that
cards are properly loaded.
Caution: If the power is ON, disconnect the Power Cable from the
Printer’s rear panel.
2 Press and hold the Pause/Resume button.
3 While holding down the Pause/Resume button, plug the power cable back into the
Printer.
4
• Full Color Ribbon Cartridge installed: The Printer will print a 3-color process
gray scale on the front of the card. The overlay pass is not printed during the
Self-test. (See Display A below)
• Premium Resin Ribbon Cartridge installed: The Printer will print a single color
gray scale on the front of the card. See Display B below)
