Using the Flipper Home Offset Option
Use this option to change the Flipper angle relative to home/horizontal position. This is done
in order to adjust angle of travel to and from the Printer and Flipper Module.
Step Procedure
1 Enter a negative value to position a card to enter the Printer at an upward
angle.
Or
Enter a positive value to position a card to enter the Printer at a descending
angle.
(Maximum Adjustment Range: The maximum adjustment range is ± 5. 1
is approximately 1 degree.)
Using the Flipper Center Offset Option
Use this option to change the card position on the Flipper Table, relative to the center, for
flipping. (Note: This is important to maintain the proper clearance with surrounding objects
when flipping a card.)
Step Procedure
1 Enter a negative value to position a card closer to the output of the Printer
when the Flipper is in home/horizontal position.
Or
Enter a positive value to position a card closer to the output of the Flipper
Module when the Flipper is in home/horizontal position.
(Maximum Adjustment Range: The maximum adjustment range is ± 127.
As a rule, 20 equals about .030”/.8 mm, which is about the same as the
thickness of a standard CR-80 size card.)
Caution: If the offset is set too high or low, the card may jam in the
Flipper Module when flipping.
