RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
6-101
Selecting the Defined Area(s) function (Front and Back options)
To define an area, refer to the following steps:
Step Procedure
1 Click Defined Area(s). (Note: This will activate the card grid in the upper half
of the window. It is through this card grid that up to five areas can be defined.)
When the card grid is first activated, a small square will appear at its default
size of .2" x .2" / 5mm x 5mm and at its default location in the lower left-hand
corner (0, 0). This square represents the first defined area.
(Note: Changing the orientation of the card in the Card Tab will change the
appearance of this Tab.)
To Next Page
