Fargo DTC400e - Using the Defined Area Option

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
6-79
Using the Defined Area Option
Step Procedure
1 a. Determine whether to use the Front option (via the Front radio button) or the
Back option (via the Back radio button).
b. Select the Defined Area(s) option to activate the card grid in the upper half
of the window. It is through this card grid that up to five (5) Defined Areas can
be assigned.
