Additional Procedures
Reviewing LED and Dipswitch Tables
The LEDs and dipswitches can be found on the back of Printers.
Reviewing the LED Table
LED DTC400e
position
Flash Rate Indicates
On once per second
(i.e., more OFF than ON)
The Normal Mode, IP
address is configured.
On twice per second The IP address is not
configured.
Off once per second
(i.e., more ON than OFF)
The Download mode is for
updating the Ethernet
interface.
STAT
LED
Upper
Off twice per second There is a system error.
On The Network link is present.
Off The Network link is not
present.
NET
LED
Lower
Blinking, off 1/3 second The Network link is present
and transmitting. It flashes
off for one-third (1/3) second
each time a packet is
transmitted.
