Using the Print Left of Form Option
Use this option to adjust the vertical position of the printed image on a card so it appears
centered. (Note: When adjusting this value, keep in mind that cards always remain in the
same landscape orientation while moving through the Printer.)
Step Procedure
1 Enter a negative value to move the image towards the bottom edge of the
card (See image below),
OR
Enter a positive value to move the image towards the back top edge of the
card (see image below).
• Maximum Adjustment Range: The maximum adjustment range is ±127.
As a rule, 10 equals about .030"/. 8mm. This is about the same as the
thickness of a standard CR-80 size card.
