Fargo DTC400e - Page 17

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
2-3
Technical Specifications (continued)
Type Description
ISO Magnetic
Encoding
• ISO: This option allows the user to select magnetic encoding that
conforms to ISO standard 7811, Parts 1-7.
• ISO Coercity: ISO magnetic encoding option provides selectable
options for either High or Low Coercivity.
See the Using the Magnetic Encoding tab
section.
Memory 2MB RAM
Monochrome
Printing
The DTC400e shall render rewriteable card images using a monochrome
color pallet.
Operating
Temperature
65° to 80° F / 18° to 27° C
Print Area CR-80 edge-to-edge
Printer
Drivers
32-bit Windows 2000/XP/2003
Print Method
• Dye-Sublimation/Resin Thermal Transfer
• Resin Thermal Transfer
Print Speed Print Speeds**
• 7 seconds per card / 514 cards per hour (K)*
• 12 seconds per card / 300 cards per hour (KO, BO)*
• 27 seconds per card / 133 cards per hour (YMCKO)*
• 35 seconds per card / 102 cards per hour (YMCKOK)*
• 35 seconds per card /102 cards per hour (YMCFOK)*
• YMCFKO – Full Color / 1 Resin Black/ Overlay/ UV Fluorescing Panel
• YMCFKOK – Full Color / 2 Resin Black/ Overlay/ UV Fluorescing
Panel
*Indicates the Ribbon type and the number of Ribbon panels printed
where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black, O=Overlay,
F=Fluorescing.
**Print speed indicates an approximate batch print speed and is measured from the time a
card feeds into the printer to the time it ejects from the printer.
Print speeds do not include encoding time or the time needed for the PC to process the
image. Process time is dependent on the size of the file, the CPU, amount of RAM and
the amount of available resources at the time of the print.
