RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
6-103
Selecting the Defined Area(s) function (continued)
Step Procedure
4 a. Once the area is sized properly measure from the lower left corner of the
card up and over to the lower left corner for the defined area to begin.
b. Enter these values into the X and Y boxes.
(Note: The card grid lines are spaced at .2 inch / 5mm intervals.)
5 a. Print the card design and note how the image is oriented on the card as it
ejects from the Printer. (Note: The location of a defined area is based on
the card orientation as it exits the Printer.)
b. Measure the defined area location based on the printed card. (Note: If
selecting Rotate Front 180 Degrees, the image will appear upside-down
as it exits the Printer. In this case, position the defined area opposite to
the measurement from the onscreen card design, which will appear right
side up.)
