Fargo DTC400e - Cleaning the Printhead

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
7-3
Step Procedure
1 Open the Printer’s Front Cover.
2 Remove the Print Ribbon.
3 Squeeze the Printhead Cleaning Swab to saturate the tip of the swab with
alcohol.
4 Use the Printhead Cleaning Swab to gently rub back and forth over the entire
length of the Printhead (3 to 4 times).
5 Once the Printhead is completely dry, replace the Ribbon and close the Front
Cover.
