RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e Card Printer User Guide (L001172 Rev. 1.1)
4-35
Resolving the Blank Output issues (continued)
Step Procedure
6 Ensure that the proper voltage is being applied to the Printhead.
a. Remove the back cover.
b. Using a Digital Voltmeter, connect the negative lead to ground.
c. Probe Pins 1 to 5 of the Printhead power connection on J16.
d. Ensure that a voltage between 22 to 23 VDC is read on each pin.
• If less than 22 volts is read on any of the pins, replace the Printhead.
• If still having issue with blank cards, replace the Main Board. (See the
current DTC400e User Guide for instructions on replacing the Main
Board in the Parts Replacement Section.)
