Alignments: Automatic Alignments
C O N F I D E N T I A L – FEI Limited Rights Data4-4
Results
The result of every step is shown by means of an icon in the result list when performing alignment steps.
FIGURE 4-1 Alignments Results
• Unavailable:
The result has never been obtained, at least not by this procedure. This may mean that it has never run, or that it
failed to do anything meaningful (the difference between these two is not important).
• Reliable:
The result is trusted by the automatic procedure or a user has passed the alignment step manually.
• Unreliable:
The automatic procedure has done meaningful work, but cannot decide whether the obtained result can be
trusted. This suggests to review the result manually.
• Out of range:
The automatic procedure trusts that the optimal outcome is outside the range of the variable to be aligned.
A value is set that is near the border of the range.
