Status
"Stat" displays the value
of
the Status Byte and Master Sunnnary Status bit. The value
is a decimal number between 0 and 255. Refer to *STB in paragraph 5.7. IEEE-488
Connnon Connnands.
Event
"Evnt" displays a value representing the contents
of
the Standard Event Status Enable
Register. The value is a decimal numberbetween 0 and 255. Refer to *ESE
in paragraph
5.7, IEEE-488 Connnon Connnands.
5.5 se
PI
PROGRAMMING EXAMPLES
Paragraph 5.5 contains a collection
of
SCPI progrannning examples. These examples
program the Model 395
tothe
same conditions as in paragraph 3.6 through 3.15; thus you
can refer to these paragraphs
if
needed
Initial Setup
Before operating the Model 395, connect the Model 395 10 the correct AC power source;
see section 2 - Initial Tum-On. Make sure the fuse in the instrument matches the fuse
required for your primary power source voltage. See Section 2, Preparation for Use,
Fuse Replacement. AIso,
be
sure the specified Hne voltage
of
the unit matches the
primary power source. Use the power cord supplied with the unit to connectthe Madel
395 to the primary power source.
Use the correct cables and terrninations
ta
connect the Madel 395
ta
an oscilloscope.
Figure 5-12 illustrates a typical setup that connects the Madel 395 Main Out
ta
channel
1
on
the oscilloscope, and the Sync Out to the scope trigger input. Cables from both
outputs must be terrninated with
50n. Some scopes contain built-in
50n
terminations.
Remote Operation 5-13
