Contents
SAFETYISSUES
READ THIS ENTIRE SECTION THOROUGHl y BEFORE ATTEMPTING TO INSTAll, OPERATE OR
SERVICE THE
MODEl 395 100MHz SYNTHESIZED ARBITRARY WAVEFORM GENERATOR ix
Section 1 Introduction
1.1 THE MODEL 395 1-1
1.2 ORGANIZATION OF THIS MANUAL.. 1-2
Section 2 Initial Preparation
2.1 THIS SECTION 2-1
2.2 RECEIVING AND INSPECTING SHIPMENTS 2-1
2.3 RETURNING EQUIPMENT FOR REPAIR 2-1
2.4 PREPARATION FOR STORAGE OR SHIPMEI\lT 2-2
2.5
UNE VOLTAGES AND FUSES 2-2
2.6 INITIAL
TURN-DN 2-4
2.7 ERROR MESSAGES 2-5
2.8 FUI\lCTIOI\lAL CHECKOUT 2-5
Continuous Mode Check 2-5
Sweep Mode Check 2-5
Gated Mode Check 2-5
Triggered Mode Check 2-6
2.9 OPERATOR MAINTENANCE 2-6
2.9.1 Routine Maintenance 2-6
2.9.2 Battery Replacement 2-7
2.10 RACK MOUNTING EARS 2-7
2.11 REMOTE SETUP 2-7
2.11.1 RS-232 2-7
2.11.2 IEEE-488 (Option 001) 2-10
Section 3 Introduction Ta The Model395
3.1 OVERVIEW OF THE MODEL 395 3-1
Using the Model 395 3-1
3.2 NAVIGATING THE SCREENS 3-1
3.2.1 Front Panel Keys and Screens 3-1
3.2.2 Softkeys 3-2
3.2.3 Extended Screens 3-2
3.2.4 Changing Numeric Values 3-3
3.2.5 Correcting Mistakes 3-4
3.3 ON-SCREEN HELP 3-4
3.4 ERROR MESSAGES 3-5
3.5 INITIAL SETUP 3-5
3.6 MODEL 395 AS A FUNCTION GENERATOR 3-6
Example 1. Setting Up the Function Generator 3-6
3.7 MODEL 395 AS
AN ARBITRARY WAVEFORM GENERATOR. 3-10
Example 2 Creating an Arbitrary Waveform Using Line Draw 3-11
Example 3 Generating the Arb Waveform 3-14
Example 4. Creating an Arb Waveform Using Waveform Insert 3-17
Example 5. Creating an Arbitrary Waveform Using Point Edit 3-19
3.8 THE MODEL 395 AS A WAVEFORM SEQUENCE GENERATOR 3-22
Example 6 Creating a Waveform Sequence 3-22
3.9 STORING AND RECALUNG SETUPS 3-24
Example 7. Storing and Recalling an Instrument Setup 3-24
3.10 THE MODEL 395 AS A SWEEP GENERATOR 3-25
Example 8. Setting up the Sweep Generator 3-25
Contents v
