Foundry Configuration Guide for the FESX, FSX, and FWSX
11 - 36 © Foundry Networks, Inc. December 2005
NOTE: Before using the method described in this section, see “Configuring VLAN Groups and Virtual Routing
Interface Groups” on page 11-40. You might be able to achieve the results you want using the methods in that
section instead.
Figure 11.14 shows an example of this type of configuration.
Figure 11.14 Multiple port-based VLANs with separate protocol addresses
As shown in this example, each VLAN has a separate IP sub-net address. If you need to conserve IP sub-net
addresses, you can configure multiple VLANs with the same IP sub-net address, as shown in Figure 11.15.
FSX
Switching Router
VLAN 2
VE 1
-IP 10.0.0.1/24
VLAN 4
VE 3
-IP 10.0.2.1/24
VLAN 2
VLAN 3
VLAN 4
VLAN 3
VE 2
-IP 10.0.1.1/24
