Foundry Configuration Guide for the FESX, FSX, and FWSX
19 - 30 © Foundry Networks, Inc. December 2005
Displaying PIM Traffic Statistics
To display PIM traffic statistics, use the following CLI method.
Syntax: show ip pim traffic
NOTE: If you have configured interfaces for standard PIM (dense mode) on the Layer 3 Switch, statistics for
these interfaces are listed first by the display.
This display shows the following information.
virtual ports Indicates the virtual interfaces to which the receivers for the source
and group are attached. The receivers can be directly attached or
indirectly attached through other PIM Sparse routers.
prune ports Indicates the physical ports on which the Layer 3 Switch has received
a prune notification (in a Join/Prune message) to remove the receiver
from the list of recipients for the group.
virtual prune ports Indicates the virtual interfaces ports on which the Layer 3 Switch has
received a prune notification (in a Join/Prune message) to remove the
receiver from the list of recipients for the group.
This Field... Displays...
Port The port or virtual interface on which the PIM interface is configured.
Hello The number of PIM Hello messages sent or received on the interface.
J/P The number of Join/Prune messages sent or received on the
interface.
Note: Unlike PIM dense, PIM Sparse uses the same messages for
Joins and Prunes.
This Field... Displays...
FastIron SuperX Router(config-pim-router)# show ip pim traffic
Port Hello J/P Register RegStop Assert
[Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx]
e3/8 19 19 32 0 0 0 37 0 0 0
Port Hello J/P Register RegStop Assert
[Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx]
v1 18 19 0 20 0 0 0 0 0 0
Port Hello J/P Register RegStop Assert
[Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx] [Rx Tx]
v2 0 19 0 0 0 16 0 0 0 0
Total 37 57 32 0 0 0 0 0 0 0
IGMP Statistics:
Total Recv/Xmit 85/110
Total Discard/chksum 0/0
