Configuring Power Over Ethernet
December 2005 © Foundry Networks, Inc. 6 - 11
Syntax: show inline power [<slot num>] | [<slot num>/<port num>]
Table 6.4 provides definitions for the statistics.
Table 6.4: Field Definitions for the Show Inline Power Command
This Column... Displays...
Power Capacity The total POE power supply capacity and the amount of available power (current
free) for POE power consuming devices. Both values are shown in milliwatts.
Power Allocations The number of times the FSX fulfilled POE requests for power.
Port The slot number and port number.
Admin State Specifies whether or not Power over Ethernet has been enabled on the port. This
value can be one of the following:
•ON – The inline power command was issued on the port.
• OFF – The inline power command has not been issued on the port.
Oper State Shows the status of in-line power on the port. This value can be one of the
following:
• ON – The POE power supply is delivering in-line power to the powered
device.
• OFF – The POE power supply is not delivering in-line power to the powered
device.
• DENIED – The port is in standby mode (waiting for power) because the FSX
does not currently have enough available power for the port.
Power Consumed The number of current, actual milliwatts that the powered device is consuming.
Power Allocated The number of milliwatts allocated to the port. This value is either the default or
configured maximum power level, or the power class that was automatically
detected by the FSX.
PD Type The type of powered device connected to the port. This value can be one of the
following:
• 802.3AF-PD – The powered device connected to this port is 802.3af-
compliant.
• LEGACY – The powered device connected to this port is a legacy product
(not 802.3af-compliant).
• N/A – Power over Ethernet is configured on this port, and one of the following
is true:
• The device connected to this port is a non-powered device.
• No device is connected to this port.
• The port is in standby or denied mode (waiting for power).
