Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-57
Table 2-21. Ethernet Input / Control Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin ETH_8 Ball M03
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z GPIO
Simple General Purpose Output
ETH7 Wire hi - z ETH_CD
Ethernet Carrier Detect
ETH7 Wire / USB2 hi - z ETH_CD
Ethernet Carrier Detect
ETH18 Wire w/o MD hi - z ETH_RXDV
Ethernet Receive Data Valid
ETH18 Wire w/ MD hi - z ETH_RXDV
Ethernet Receive Data Valid
EHT7 Wire, UART4e, J1850 hi - z ETH_CD
Ethernet Carrier Detect
ETH7 Wire, J1850 hi - z ETH_CD
Ethernet Carrier Detect
UART_4, UART5e, J1850 hi - z UART5e_DCD
Uart Carrier Detect
UART5e, J1850 hi - z UART5e_DCD
Uart Carrier Detect
J1850 hi - z GPIO
Simple General Purpose Output
Pin ETH_9 Ball L01
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z GPIO
Simple General Purpose Output
ETH7 Wire hi - z ETH_RXCLK
Ethernet Receive Clock
ETH7 Wire / USB2 hi - z ETH_RXCLK
Ethernet Receive Clock
ETH18 Wire w/o MD hi - z ETH_RXCLK
Ethernet Receive Clock
ETH18 Wire w/ MD hi - z ETH_RXCLK
Ethernet Receive Clock
EHT7 Wire, UART4e, J1850 hi - z ETH_RXCLK
Ethernet Receive Clock
ETH7 Wire, J1850 hi - z ETH_RXCLK
Ethernet Receive Clock
UART_4, UART5e, J1850 hi - z ETH_RXCLK
Ethernet Receive Clock
UART5e, J1850 hi - z UART5e_CTS
Uart Clear To Send
J1850 hi - z UART5e_CTS
Uart Clear To Send
